Details
- 10 outlets configured in 6 isolated sections
- Toroidal transformer with additional electromagnetic field shielding
- 2 powerful AC sections with 800mA each
- 9, 12 and 16V AC available
- One AC section convertible into a 600mA DC section
- 15V option for Radial Tonebone pedals
- Short circuit protection of all outlets
- Advanced LED monitoring of each section
- 120 or 230V mains voltage operation
- Total of 16 Flex cables in total included
- Split Flex for powering two pedals of one outlet included
- Stack Flex and Series adapter Flex for powering 18 or 24V pedals included
- Flex cable for Electro-Harmonix vacuum tube pedals included
- Compatible with Pedaltrain and Temple Audio pedalboards
- Mounting bracket and all pedalboard mounting hardware included
Outlet 1-2: 9V DC / 100mA each
Outlet 3-4: 9 or 12V DC / 200mA each
Outlet 5-6: 9 and 12 or 15V DC / 600mA*
Outlet 7-8: 9 or 12V AC / 800mA*
Outlet 9-10: 9, 12 or 16V AC / 800mA
* only one of these two sections can be usedSize: 158x98x35mm (excl. rubber feet)
Weight: 1,1kg- CIOKS AC10 power supply
- Mains power cord
- 17 Flex cables:
- Type 1 – black with 5,5/2,1mm centre negative DC plug x8
- Type 2 – red with 5,5/2,1mm centre positive DC plug x1
- Type 4 – green with 5,5/2,5mm centre positive DC plug x2
- Type 5 – black with 3,5mm tip positive Jack plug x1
- Type 6 – black with 9V battery clip x1
- Type 7 – blue with 2 pin DIN plug x1
- Split Flex type 1 – powers two pedals of a single outlet x1
- Stack Flex type 1 – white/black, adds voltages of two outlets x1
- Pedalboard mounting hardware: mounting bracket, screws, washers, stand-off and a hex key
- Manual
- Product sheet (drill guide)
- Flex guide
