Color |
Black, white |
Input Connections |
4-pin Phoenix |
Nominal Impedance |
8 Ω |
Speaker Type |
Full-range, Mid-High, Two-Way |
Frequency Response (-3 dB) |
60 - 20000 Hz |
Frequency Response (-10 dB) |
48 - 20000 Hz |
Internal Crossover |
Yes |
Recommended High-Pass Frequency |
40 Hz |
Sensitivity 1 W/1 m |
94 (90x50), 92 (100x100) dB |
Max. SPL/1m (calc) |
123 (90x50), 121 (100x100) dB |
Coverage (Nominal -6 dB) H |
90/100 ° Rotatable |
Coverage (Nominal -6 dB) V |
50/100 ° Rotatable |
Rotatable Horn |
Yes |
System Power Handling (Continuous/Program/Peak) |
200/400/800 Watts |
LF Transducer |
EV8L 8-inch Weatherized Cone |
HF Transducer |
DH2005 1-in Exit True Compression Driver |
Crossover Frequency |
1700 Hz |
Minimum Impedance |
6 Ω |
Enclosure Material |
High Impact Polystyrene |
Flying |
Yes |
Outdoor |
Yes |
Grill |
Polyester Powder Coated, 18GA Galvanized Steel |
Height |
451 mm (17.76") |
Width |
282 mm (11.1") |
Depth |
263 mm (10.35") |
Weight Net |
8.4 kg (18.52 lbs) |
